V-PG-3A Pocket Coil Glueing Machine
▲ High efficiency glueing machine, operating speed can reach 6rows/minute.
▲ None, Single-sided or Double-sided non-woven cover for glueing is available.
▲ Paralleled or Nested pocket spring glueing is available.
▲ Continued spray or Intermittent spray glue is optional, save up the glue cost.
▲ Easy to operate and maintain.
Technical parameters:
Production capacity: 190 mattresses (single size) / 8 hours
110 mattresses (queen size) / 8 hours
Non-woven cover maximum width: 2200mm
Spring central diameter: 25mm-80mm
Pocket spring height: 40mm-390mm
Power supply: 3phase 380V 4kw
Air Consumption: approx 15m3/hour 0.8mpa
Weight: 2000kg
Overall Dimension: 3800x1650x1800mm
4000x1860x2050mm
